| Model: HP15 | Model: HP20 | Model: 2HP20 |
| Max. head: 55m | Max. head: 60m | Max. head: 75m |
| Flow: 30m3/h | Flow: 30m3/h | Flow: 30m3/h |
| Suction head: 7m | Suction head: 7m | Suction head: 7m |
| Diameter of suction pipe : 40mm (1.5 inch) | Diameter of suction pipe : 50mm (2 inch) | Diameter of suction pipe : 50mm (2 inch) |
| Diameter of discharge pipe (1st): 40mm (1.5 inch) | Diameter of discharge pipe(1st) : 50mm (2 inch) | Diameter of discharge pipe(1st) : 50mm (2 inch) |
| Diameter of discharge pipe(2nd):20mm (1.0 inch) | Diameter of discharge pipe(2nd):40mm (1.5 inch) | Diameter of discharge pipe(2nd):40mm (1.5 inch) |
| Diameter of discharge pipe(3nd):20mm (1.0 inch) | Diameter of discharge pipe(3nd):40mm (1.5 inch) | Diameter of discharge pipe(3nd):40mm (1.5 inch) |
| Pump material: Aluminum | Pump material: Aluminum | Pump material: Aluminum |
| Impeller material: Aluminum | Impeller material: Aluminum | Impeller material: Aluminum |
| Impeller quantity: 1 PC | Impeller quantity: 1 PC | Impeller quantity: 2 PC |
| Connector material: Plastic | Connector material: Plastic | Connector material: Plastic |
| Engine model: PT170F | Engine model: PT170F | Engine model: PT170F |
| Max engine output: 7.0HP | Max engine output: 7.0HP | Max engine output: 7.0HP |
| Fuel capacity: 3.6L | Fuel capacity: 3.6L | Fuel capacity: 3.6L |
| Start system: Hand recoil start | Start system: Hand recoil start | Start system: Hand recoil start |
