展品型号:1.4T/1.6吨电动堆垛车
展品尺寸:1920*870*2019MM
展品材质:钢铁、橡胶、塑料等
发 货 地:中国 浙江
展品颜色:橘红色
展品特征:本公司主打产品,绿色环保,智能产品
品名: 1.4T/1.6吨电动堆垛车
特性: 安全/舒适/大载荷/持久
型号: HEPS14/HEPS16
1 | Model型号 | HEPS14/16 | |
2 | Operation type 操作类型 | Rider/walkie | |
3 | Load capacity 额定载荷 | kg | 1400/1600 |
4 | Load center 载荷中心距 | mm | 600 |
5 | Service weight(with battery) 带电瓶自重 | kg | 1080 |
6 | Steering/bearing tyres material 驱动轮/承载轮材料 | -- | PU/PU |
7 | Mast lower height 静止高度 | mm | 2019 |
8 | Lift height 起升高度 | mm | 3000/3300/4000 |
9 | Lowered fork height 离地间隙 | mm | 85 |
10 | Overall length with forks 总长 | mm | 1920 |
11 | Overall width 总宽 | mm | 870 |
12 | Fork length×width×height 货叉长×宽×高 | mm | 1150×185×55 |
13 | Turning radius 转弯半径 | mm | 1600 |
14 | Travel speed(laden/unladen) 行驶速度(承载/空载) | km/h | 4.5/7 |
15 | Gradeability speed(laden/unladen) 爬坡度(承载/空载) | ° | 5/7 |
16 | Drive motor output 驱动电机功率 | kW | 1.5 |
17 | Lifting motor output 起升电机功率 | kW | 2.0 |
18 | Battery voltage/capacity 电瓶电压/容量 | v/AH | 24/210 |
19 | Control system 驱动控制类型 | -- | AC |
20 | Manufacturer of control system 控制器制造商 | -- | CURTIS |
