钢丝绳输送带

Item

ST630

ST800

ST1000

ST1250

ST1600

ST2000

ST2500

ST3150

ST3500

ST4000

ST4500

ST5000

ST5400

Tensile strength(N/mm)

630

800

1000

1250

1600

2000

2500

3150

3500

4000

4500

5000

5400

Diameter(mm)

3

3.5

4.0

4.5

5.0

6.0

7.2

8.1

8.6

8.9

9.7

10.9

11.3

pitch(mm)

10±1.5

10±1.5

12±1.5

12±1.5

12±1.5

12±1.5

15±1.5

15±1.5

15±1.5

15±1.5

16±1.5

17±1.5

17±1.5

Top cover thickness(mm)

5

5

6

6

6

8

8

8

8

8

8

8.5

9

Bottom cover thickness(mm)

5

5

6

6

6

8

8

8

8

8

8

8.5

9

Width (mm)

Number of steel cord

ST630

ST800

ST1000

ST1250

ST1600

ST2000

ST2500

ST3150

ST3500

ST4000

ST4500

ST5000

ST5400

800

75

75

63

63

63

63

50

50

50

1000

95

95

79

79

79

79

64

64

64

64

59

55

55

1200

113

113

94

94

94

94

76

76

77

77

71

66

66

1400

133

133

111

111

111

111

89

89

90

90

84

78

78

1600

151

151

126

126

126

126

101

101

104

104

96

90

90

1800

171

143

143

143

143

114

114

117

117

109

102

102

2000

159

159

159

159

128

128

130

130

121

113

113

2200

176

141

141

144

144

134

125

125

2400

193

155

155

157

157

146

137

137

Note: 1. Thickness of cover rubber, Diameter of steel cord and pitch of steel cord can be customized according to the requirement of the customer after negotiation.

2. The belt can be produced according to the requirement of the customer under the standards of the German DIN22131, Australia AS133, Japan JISK6369, etc
