棉布输送带

起订量：协议

展品参数

展品型号：CC56/TC70 棉布输送带

展品尺寸：350mm-2000mm

展品材质：橡胶

发货地：中国浙江

展品颜色：黑色

展品特征：本公司主打产品

洽议预约

展品详情

Overview

Quick Details

Place of Origin:: Zhejiang, China

Brand Name:: HUJIA

Model Number:: CC56/TC70 Cotton Conveyor Belt

OEM:: Available

Fabric Plies:: 2-10

Width:: 350mm-2000mm

Length:: 10m-400m/roll

Thickness:: 6-30mm

Certificate:: ISO9001:2008

Condition:: New

Supply Ability

Supply Ability:: 3000 Meter/Meters per Day

Packaging & Delivery

Packaging Details: Packing with one ply ultraviolet radiation resistant cloth or according to the customers' need.

Port: Ningbo Port/ Shanghai Port

Lead Time :: Shipped in 25 days after payment

first figure

Flat Belt Conveyor Cotton Canvas CC56 High Quality Chicken Cotton Fabric

Product information

Fabric Type

Fabric Texture

Fabric

Model

Rubber Fabric

Thickness

(mm/p)

Strength Series(N/mm)

Thickness of Cover RUBBER

Width

Range

(mm)

Belt

Length

(m)

Layer

Upper Cover

Rubber

Lower Cover

Rubber

Warp

Weft

ALL-cotton

(CC)

Cotton

(C)

Cotton

(C)

CC-56

1.10

112

168

224

280

336

2~8

0~4.5

350~2000

≤300

Polyester

Cotton

(TC)

Polyester

Cotton

(TC)

Cotton

(C)

TC-70

1.0

140

210

280

350

420

1.5~8

0~4.5

350~2000

≤300

Classification of Cover Layer Propenty of Rubber Belt Based on Table as following

Cover Layer Class	Tensile Strength ≥		Elongation at Break ≥	Wear Loss ≤	Change Rate of Tensile Strength and Elongation at Break after Aging
Cover Layer Class	MPa	kgf/cm²	%	cm²/1.61km	%
Heavy Type(H)	18	180	400	0.7	-25~+25
Common Type(M)	14	140	350	0.8	-25~+25
Light Type	10	100	300	1.0	-30~+30

Bonding Strength and Elingation Property Table

Belt Core Material	Bonding Strength			Elongation
	Between Fabric Layers (N/mm)	Between Cover Layer and Fabric Layer		Longitudinal Elongation at Break through Thickness% ≥	Longitudinal Reference Force Elongation throughThickness%≤
		Thicness of Cover Layer≤1.5mm	Elongation Property≥1.5mm
ALL-cotton Canvas	≥2.70	≥2.4	≥2.7	10	2.0

Advantages

Flat Belt Conveyor Cotton Canvas CC56 High Quality Chicken Cotton Fabric

Product Information

Rubber Grade		Tensile Strength		Elongation	Abrasion	Adhesion
		MPA	KGF	%	MM3	Cover to Ply(N/MM)	Cover to Ply(N/MM)	Ply to Ply(N/MM)
DIN 22102- 1991	W	18	180	400	90	3.5	4.5	5.0
	X	25	250	450	120	3.5	4.5	5.0
	M	25	250	450	150	3.5	4.5	5.0
	Y	20	200	400	150	3.5	4.5	5.0
	N	20	200	400	200	3.5	4.5	5.0
	Z	15	150	350	250	3.5	4.5	5.0
	D	15	150	350	250	3.5	4.5	5.0
	O	10	100	300	300	3.0	4.0	4.5
AS 1332- 1991	A	17	170	400	70	4.0	4.8	6.0
	M	24	240	450	125	4.0	4.8	6.0
	N	17	170	400	200	4.0	4.8	6.0
	S	14	140	300	250	3.0	4.0	5.0
JIS K6322-1 988	S	18	180	450	200	3.5	3.2	4.5
	G(1)	14	140	400	250	3.5	3.2	4.5
	L(2)	8	80	300	400	3.5	3.2	4.5
	A	14	140	400	150	3.5	3.2	4.5
ISO 10247	H	25	250	450	120	3.5	3.2	4.5
	D	20	200	400	100	3.5	3.2	4.5
	L(2)	15	150	350	200	3.5	3.2	4.5
BS 490-1990	M(24)L	24	240	450	150	4.0	4.5	5.0
BS 490-1990	N17(N)	17	170	400	220	4.0	4.5	5.0
RMA -1989	1	17	170	400	220	3	4.4	4.0
RMA -1989	2	14	140	300	250	3	4.4	4.0
