旋涡泵

Applications:
 1. Transfer clean water or other liquids similar to water in physical and chemical properties
 2. Small living water supply, automatic water sprinkler system, Small air conditioner system,

Supporting equipment, etc.

Pump:

1. Special anti-rust treatment for cast iron pump body and support
2. Anti-block system for impeller

3. Brass impeller
4. AISI 304 shaft
5. Max. liquid temperature:+60℃
6. Max. Suction:+8m

Motor:
1. C&U bearing
2. Motor with copper winding
3. Buit-in thermal protector for single phase motor

4. Insulation class:F
5. Protection class:IPX4
6. Max. Ambient temperature:+40℃
7. IE2 motor (APS110,APS150)
