Serial No. : DL4-30
Material:Stainless-steel、Iron-cast
Place of origin:Zhejiang China
Color:BLACK
Support level: A
Registered capital:1000
Founded:2014
Number of companies:101-500人
Export scale:
Contact: ***
E-Mail：Sign In
Tel:Sign In
Model | Power
| Q | m3/h | 2 | 3 | 4 | 5 | 6 | 7 | 8 | |
Three phase 380V 50Hz | KW | HP | l/min | 33.3 | 50 | 66.7 | 83.3 | 100 | 116.7 | 133.3 | |
| Head(m) | |||||||||||
| DL4-20 | 0.37 | 0.5 | H(m) | 18 | 17 | 16 | 15 | 14 | 10 | 6 | |
| DL4-30 | 0.55 | 0.75 | 26 | 25 | 24 | 22.5 | 20 | 12 | 7.5 | ||
| DL4-40 | 0.75 | 1.0 | 35 | 33.5 | 32 | 29.5 | 26.5 | 16 | 10 | ||
| DL4-50 | 1.1 | 1.5 | 43 | 40 | 37 | 33 | 28 | 23 | 12 | ||
| DL4-60 | 1.1 | 1.5 | 52 | 50 | 45 | 41 | 34 | 25 | 14 | ||
| DL4-70 | 1.5 | 2.0 | 61 | 58 | 53 | 47.5 | 40 | 28 | 18 | ||
| DL4-80 | 1.5 | 2.0 | 70 | 66.5 | 61 | 54 | 46 | 32 | 21 | ||
| DL4-100 | 2.2 | 3.0 | 86 | 80 | 74 | 66 | 56 | 41 | 23 | ||
| DL4-120 | 2.2 | 3.0 | 105 | 99 | 91 | 82 | 68 | 47 | 27 | ||
| DL4-130 | 2.2 | 3.0 | 114 | 107 | 97.5 | 57 | 74 | 53 | 31 | ||
| DL4-140 | 2.2 | 3.0 | 123 | 116 | 106 | 93 | 79 | 56 | 33.5 | ||
| DL4-150 | 3.0 | 4.0 | 131 | 124 | 112.5 | 100 | 85.5 | 61 | 36 | ||
| DL4-160 | 3.0 | 4.0 | 142 | 133 | 122 | 111 | 93 | 67 | 38 | ||
| DL4-170 | 4.0 | 5.5 | 149 | 140 | 127.5 | 114 | 97 | 70 | 41 | ||
| DL4-180 | 4.0 | 5.5 | 158 | 149 | 135 | 121 | 103 | 74 | 43 | ||
| DL4-190 | 4.0 | 5.5 | 166 | 157 | 143 | 127.5 | 111 | 78 | 47 | ||
| DL4-200 | 4.0 | 5.5 | 175 | 165 | 150 | 134 | 115 | 82 | 49 | ||
| DL4-210 | 4.0 | 5.5 | 184 | 173 | 157.5 | 141 | 120 | 86 | 51 | ||
| DL4-220 | 4.0 | 5.5 | 190 | 180 | 164 | 146 | 124 | 91 | 54 | ||
