SOLAR PANELS

Min. Order: 67 pc

Product Parameters

Serial No. : KDM-POLY290-60

Size（mm）：1640X992X35

Material:Polycrystalline

Place of origin:Jiangsu China

Color:BLUE

Schedule an Appointment

Support level: A

NO.1199 HUIFENG SOUTH ROAD, JIANGNAN DEVELOPMENT AREA,LINHAI, ZHEJIANG,CHINA

Registered capital:51198000

Founded:2009

Number of companies:101-500人

Export scale:

Contact: 林**

E-Mail：Sign In

The detailed information

High quality practical portable solar panel

Product Description

Model	KD-P260	KD-P270	KD-P275	KD-P280	KD-P285
Wattage	260W	270W	275W	280W	385W
Open circuit voltage (Voc)	37.98	38.2	38.4	38.7	38.9
Maximum Power Voltage(Vmp/V)	30.62	31.2	31.5	31.6	31.8
Short Circuit Current(Isc/A)	9.04	9.2	9.28	9.46	9.54
Maximum Power Current(Imp/A)	8.5	8.66	8.65	8.86	8.96
Module Efficiency	15.88%	16.60%	16.48%	17.21%	17.53%
Standard Test Condition(STC)	Irradiance 1000w/m2, Cell Temperature 25 Centigrade, Air Mass 1.5

Product Details

Hot Products

Workshop&packing

Project

Payment

Certification

Product exhibition plan
