Serial No. : YB150T-11
Size（mm）：2180*710*1150
Place of origin:Zhejiang China
Color:optional
Support level: A
Registered capital:2900
Founded:2016
Number of companies:200-500人
Export scale:
Contact: 程**
E-Mail：Sign In
Tel:Sign In
| Main technical data | |||
| Model | YB50QT-23 | YB125T-23C | YB150T-11C |
| Dimension(mm) | 2180x710x1150 | 2180x710x1150 | 2180x710x1150 |
| Wheel base (mm) | 1400 | 1400 | 1400 |
| Min clearance（mm) | 140 | 140 | 140 |
| Net weight (kg) | 120 | 120 | 120 |
| Max load (kg) | 150 | 150 | 150 |
| Max speed (km/h) | 85 | 85 | 85 |
| Brake(Fr./Rr.) | Disk / Drum | Disk / Drum | Disk / Drum |
| Wheel hub (Fr./Rr.) | Aluminium | Aluminium | Aluminium |
| Tyre size (Fr./Rr.) | 100/80-16/110/80-16 | 100/80-16/110/80-16 | 100/80-16/110/80-16 |
| Wheel atmosphere(Fr./Rr.) | 220/250(kPa) | 220/250(kPa) | 220/250(kPa) |
| Consumption (L/100km) | 2.1 | 2.6 | 2.8 |
| Engine model | 139QMB | 152QMI | 157QMJ |
| Engine type | 1-Cylinder,4-Stroke,air-cooled | 1-Cylinder,4-Stroke,air-cooled | 1-Cylinder,4-Stroke,air-cooled |
| Max power (kw/(r/min)) | 2.1/7000 | 5.0/7000 | 5.8/7000 |
| Max torque (N·m/(r/min)) | 7.0/7000 | 8.6/7000 | 9.3/7000 |
| Ignition | C.D.I | C.D.I | C.D.I |
