200cc Shaft Engine Tricycle Motorcycle Scooter ATV (JL175ZK) CCC CE

Min. Order: 3 piece

Product Parameters

Serial No. : JL175ZK

Size（mm）：2025×1220×1000

Place of origin:Zhejiang China

Color:red, white, black, blue, grey, etc

Schedule an Appointment

Support level: A

NO.588 LINGSHAN WEST STREET, LUQIAO, TAIZHOU CITY, ZHEJIANG PROVINCE, CHINA

Registered capital:5500

Founded:1995

Number of companies:101-500人

Export scale:

Contact: 潘**

E-Mail：Sign In

The detailed information

SPECIFICATION	200CC
DIMENSION (L×W×H mm)	2025×1220×1000
ENGINE TYPE	Single cylinder, 4 stroke, air cooling
DISPLACEMENT(ML)	177.3ml
MAX.POWER(KW/R/MIN)	6.8/7500(kw/ r/min)
MAX.TORQUE(N.M/R/MIN)	10/6000r/min
COMPRESSION RATIO	10：1
BORE AND STROKE(MMxMM)	62.5×57.8
IGNITION METHOD	CDI
LUBRICATION METHOD	Pressure spray
MIN.FUEL CONSUMPTION(G/KW.H)	367
STARTING METHOD	ELECTIR
CLUTCH METHOD	Dry automatic centrifugal
GEARSHIFT METHOD/CHANGGEAR METHOD)	CVT
Final Gear Ratio	1.411
CVT	2.508~0.842
LUBRICATING OIL	10W/40SF
WHEEL BASE(MM)	1500
Distance of wheel(MM)	1050
Kerb mass(KG)	168
MAXIMUM LOAD(KG)	150
FUEL TANK (L)	15
SPEED MAX.(KM/H)	84
FRONT BRAKE/REAR BRAKE	DISK BRAKE/DISK BRAKE
FRONT TIRE/REAR TIRE	(140/60-14)/(235/30-14)
FUEL BRAND	UNLEADED GASOLINE≥RQ92
CARBURETOR TYPE	PD26J
PRICE (EXW) in CBU	$1,500

Product exhibition plan
