Composite SMC Roof Mould Truck Mold

SMC is a mixture of polymer resin, insert fillers, fiber reinforcement, catalyst, pigments, stabilizers, release agents, and thickeners. Manufacturing of SMC is a continuous in-line process.

This process produces high strength, complex parts in a wide variety of sizes. Matched metal dies are mounted in a hydraulic molding press. The material charge is manually or robotically placed in the mold; the heated mold halves are closed, and up to 2000 psi of pressure is applied. Cycle time ranges from one to five minutes, depending on part size and thickness. Features such as ribs, bosses and inserts can be molded in.

Compression molded fiberglass parts are characterized by net size and shape, two excellent finished surfaces, and outstanding parts-to-part repeatability. Trimming and finishing costs are minimal.

In-mold coatings and vacuum system in the tool are available to improve surface paint ability, eliminating the need for primer.

Color compounds can be customized.

The advantage of SMC molding parts is as follows:

1. Good dimensional stability, including excellent thermal resisitance.

2. Pigmentable for molded-in color, best appearance with mold texture.

3. Excellent property retention in cold and hot environments.

4. Suitable for outdoor use in applications involving UV exposure and water.
