sigle board IGBT inverter welding machine welder XT-160I

Min. Order: 100
Product Parameters

Serial No. : sigle board IGBT inverter welding machine welder XT-160I

Size(mm):375*200*275

Material:PCB BOARD.IRON.PLASTIC

Place of origin:Zhejiang China

Color:blue( can be customize)

ZHEJIANG LAOSHIDUN TECHNOLOGY CO.,LTD

Support level: A

XIACHENG MECHANICAL INDUSTRIAL AREA, WUGEN TOWN, WENLING CITY, ZHEJIANG PROVINCE, CHINA

Registered capital:1000

Founded:2005

Number of companies:200-500人

Export scale:

Contact: 张**

E-Mail:Sign In

Tel:Sign In

The detailed information
troduction

What is the MMA welding machine?

MMA welding machine is the oldest and still the most commonly arc welding process,although the proportion of MMA use is decreasing as gas-shielded welding processes are becoming more popular,and MMA wleding (metal arc)does not require shielding gas,protection for weld pool comes form the electrode cober wheich melts during welding,and forms a protective laer of slag on the weld pool,when the welding is completed and the layer of slag is removed,the finished weld will be discovered underneath.

Where is the MMA welding machine can be use?

The MMA welding machine can be use for many different industry area,such as pipeline welding,shipbuilding industry,buliding industry and also can make the DIY welding.

This MMA welding machine can be use for pipeline welding.

This MMA welding machine can be use for shipbuilding industry.

This MMA welding machine can be use for the building industry.

Product Description

ITEM
XP-140I
XP-160I
XP-180I
Power voltage(V)
AC220V±15%50HZ
AC220V±15%50HZ
AC220V±15%50HZ
Rated input capacity(KVA)
6.1
7.2
8.3
Rated input current(A)
27.8
32.8
38.1
Rated output(A)
140A/25.6V
160A/26.4V
180A/27.2V
Output current range(A)
30-140
30-160
30-180
No-load voltage(V)
67
67
67
Duty cycle(%)
60
60
60
Efficency(%)
80
80
80
Power factor
0.73
0.73
0.73
Insulation class
F
F
F
Protect class
IP21S
IP21S
IP21S
Usable electrode(mm)
1.6-3.2
1.6-4.0
1.6-4.0
Dimension(mm)
375*240*275
375*240*275
375*240*275
Weight(kg)
5.5
5.7
6


Feature

•Advanced (IGBT) inverter technology.

•Compact,portable,high efficiency,low consumption ,energy saving.Anti-stick,thermostatic control,fan cooled,carrying strap and handle.

•Hot start,arc force,overload protection.

•Supplied complete with electrode holder and earth clamp,face mask and welding brush.

•Applicable for welding or all kinds of ferrous metal such as low carbon steel,mediun carbon steel and alloy steel,etc.







Certifications
About Laston
Exhibition Show
Packing & Delivery
Packaging
Size
0.43*0.375*0.505
Weight
18Kg



Packaging Details
The normal package is kraft box and color box 4 in 1. If the customer has a request,we can mask according to the customer's requirements.
FAQ

Q: Are you trading company or manufacturer ?
A: We are factory.

Q:How many people in your factory?
A:About 300 people.

Q:Where is your factory located?
A: Our factory is located in Xiacheng Mechaical Industrial Area,Wugen Town,Wenling City, Zhejiang Province, China.

Q: How can i visit your company?
A:You can fly to Taizhou airport, Ningbo airport or Shanghai air port. Or you can take train to Wenling Station. Then inform us, we'll come to pick you up!

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q:How do you control the quality?
A:Before we produce the machine,we have the IQC to check the materials first and when we produce,the QC will check the machine which in the product line,and when we finished the QC will check it again and also before we send the goods to you,you can come to our factory checking.
