MIG-135H INVERTER WELIDNG MACHINE AC/DC

Min. Order: 100 pcs

Product Parameters

Serial No. : MIG-135H

Material:MIG-135H

Add to Favorites

Schedule an Appointment

ZHEJIANG LAOSHIDUN TECHNOLOGY CO.,LTD

Support level: A

XIACHENG MECHANICAL INDUSTRIAL AREA, WUGEN TOWN, WENLING CITY, ZHEJIANG PROVINCE, CHINA

Registered capital:1000

Founded:2005

Number of companies:200-500人

Export scale:

Contact: 张**

E-Mail：Sign In

Tel:Sign In

The detailed information

Product Description

Product Description

1.IGBT Inverter technology, energy saving

2.PWM pulse width control, technology,special performance, accurate current control, stable arc passing.

3.Slow wire feeding ,arc end with small balls clean, electronic and inductance regulating, shielding gas post flow functions:well spatter control, good depth of fusion,good welding effect.

4.Over current. over heat. over load over voltage protection.Special appearance wire feeder integrated portable.

5.Suitable for welding mild steel，low alloy steel metal sheet.

ITEM	MIG-100H	MIG-135H
Power voltage(V)	220V	220V
Rated input capacity(A)	3.25	4.79
Rated input current(A)	19	20.75
Actual output current(A)	100	135
No-load voltage(V)	55	55
Duty cycle(%)	100	60
Efficency(%)	80	80
Power factor	0.73	0.73
Insulation class	F	F
Protect calss	IP21S	IP21S
Usable wire(mm)	0.6-0.8	0.6-0.8
Dimension(mm)	480220340	480220340
Weiaht(kg)	10.9	11.05
