Product Description

Heat resistant conveyor belt

Product description

The THREEV brand heat resistant conveyor belt is specially designed for conveying the high-temperature materials,
has excellent heat resistance, and can still keep excellent ageing resistance under the severe environment in the high temperature conveying process; prolong service life.

Applicable environment: metallurgy, cement plant, casting factory, fertilizer factory, and high-temperature environment

Technical data

Item			classes
			T1	T2	T3	T4
			Test temperature
			≤100℃	≤125℃	≤150℃	≤175℃
			change range allow
hardness		The difference between the before and after aging	+20	+20	±20	±20
hardness		Maximum value after aging	85	85	85	85
Tensile strength		Performance change rate	-25	-30	-40	-40
Tensile strength		Minimum value after aging	12	10	5	5
elongation		Change rage after aging	-50	-50	-55	-55
elongation		Minimum value after aging	200	200	180	180
adhesive	Top cover rubber to ply	average value	2.1
	Top cover rubber to ply	Minimum value	1.7
	Ply to ply	Average value	2.1
	Ply to ply	Minimum value	1.7
	Ply to Bottom cover rubber	Average value	2.1
	Ply to Bottom cover rubber	Minimum value	1.7

The data are only for type selection of the conveyor belt and Zhejiang Sanwei Rubber Item Co.,LTD. has the final explanation right

--Product Display -----------------------------------------------------------------------------------------

--Production Process-----------------------------------------------------------------------------------------

--Factory Site --------------------------------------------------------------------------------------------------

--Certificate----------------------------------------------------------------------------------------------------

Product exhibition plan

Heat resistant conveyor belt

SANWEI HOLDING GROUP CO., LTD

Heat resistant conveyor belt
