2 inch, 3 inch, 4 Inch Air-Cooled 4-Stroke Gasoline Water Pump
High pressure pump, Perfect for! Irrigation, Watering, Farming, Fire Fighting, Deep well water, Agriculture etc.
| Type | WP10 | WP20 | WP30 | WP40A | WP40 |
| Outlet Size(mm) | 25.4(1 inch) | 50(2inch) | 80(3inch) | 100(4inch) | 100(4inch) |
| Inlet size(mm) | 25.4(1 inch) | 50(2inch) | 80(3inch) | 100(4inch) | 100(4inch) |
| Speed (rpm) | 3600 | 3600 | 3600 | 3600 | 3600 |
| Displacement Q.max(m3/h) | 18 | 30 | 60 | 90 | 90 |
| Lift H.max(m) | 14 | 25 | 28 | 25 | 25 |
| Suction(m) | 6 | 7 | 7 | 7 | 7 |
| Engine Model | 154F | 168F | 168F-1 | 170F | 188F |
| Engine Type | |||||
| Bore x Stroke(mm) | 54*38 | 68x45 | 68x54 | 70x | 88x64 |
| Displacement(cm3) | 87 | 163 | 196 | 389 | |
| Compression Ratio | 7.7:1 | 8.5:1 | 8.5:1 | 8.0:1 | |
| Max Power Output(HP/rmp) | 2.5/3600 | 5.5/3600 | 6.5/3600 | 7.5/3600 | 13/3600 |
| Max Torque(Nm) | 3.5 | 10.8 | 13.2 | 26.5 | |
| Start Model | Recoil and hand -operated | ||||
| Air Cleaner | semi-dry | ||||
| Fuel Tank Capacity (L) | 1.6 | 3.6 | 3.6 | 3.6 | 6.5 |
| Min Fuel Consumption(g/Kw.h) | 360 | 360 | 360 | 360 | 325 |
| Oil Capacity(L) | 0.37 | 0.6 | 0.6 | 0.6 | 1.1 |
| Packing Dimensions (mm) | 450*345*360 | 485x385x380 | 510x385x425 | 515x390x445 | 635x455x545 |
| G.W/N.W(Kg) | 17 | 22 | 23 | 25 | 43/42 |
