SPECIFICATION | 125CC | 110CC |
Dimension(L×W×H)(mm) | 1850X715X1070 | 1850X715X1070 |
Wheel Base(mm) | 1240 | 1240 |
Net Weight(Kg) | 95 | 95 |
Engine Model | 1P52QMI | 1P50QMH-2 |
Bore×Stroke(mm) | 52.4×57.8 | 50×55.1 |
Engine Type | laying, single cylinder, 4 stroke | laying, single cylinder, 4 stroke |
Displacement(ml) | 124.6 | 108.2 |
Maximum Speed(Km/h) | ≥80 | 80 |
Maximum power KW/(r/min) | 5.6/7500 | 6.0/7500 |
Max. Torque (NM(kg-m)/rpm) | 7.2(6000±500) | 8.5(6000±500) |
Front Brake | disc by handle | disc by handle |
Rear Brake | drum by handle | drum by handle |
Front Tire Size | 70/90-14 | 70/90-14 |
Rear Tire Size | 90/90-14 | 90/90-14 |
Front/Rear Wheel Hub | aluminium | aluminium |
Starting Mode | electric and kick start | electric and kick start |
Idling Speed (r/min) | 1700 | 1700 |
Fuel Tank Capancity (L) | 3.6 | 3.6 |
Fuel consumption (L/100km) | 2.8 | 2.8 |
Lubrication System | pressure, spray | pressure, spray |
Battery | 12V7AH | 12V7AH |
Package Size | 1780*570*1100mm(remove front wheel) 1780*570*870mm(remove front wheel and Handle bar) | |
Quantity in 20FT/40HQ | 24 units(remove front wheel) in 20FT. 48 units(remove front wheel) in 40GP. 78units(remove front wheel and Handle bar)in 40HQ |
