| Main technical data | |||
| Model | YB50QT-27 | YB125T-27 | YB150T-27 |
| Dimension(mm) | 1955*680*1140 | 1955*680*1140 | 1955x680x1145 |
| Wheel base (mm) | 1380 | 1380 | 1380 |
| Min clearance（mm) | 110 | 85 | 110 |
| Net weight (kg) | 85 | 95 | 95 |
| Max load (kg) | 150 | 150 | 150 |
| Max speed (km/h) | 45 | 85 | 85 |
| Brake(Fr./Rr.) | Disk / Drum | Disk / Drum | Disk / Drum |
| Wheel hub (Fr./Rr.) | Fr2.75×12/Rr3.00×12 | Fr2.75×12/Rr3.00×12 | Fr2.75×12/Rr3.00×12 |
| Tyre size (Fr./Rr.) | 120/70-12 | 120/70-12 | 120/70-12 |
| Wheel atmosphere(Fr./Rr.) | 220/250(kPa) | 220/250(kPa) | 220/250(kPa) |
| Consumption (L/100km) | 2.1 | 2.6 | 2.8 |
| Engine model | 139QMB | 152QMI | 157QMJ |
| Engine type | 1-Cylinder,4-Stroke,air-cooled | 1-Cylinder,4-Stroke,air-cooled | 1-Cylinder,4-Stroke,air-cooled |
| Max power (kw/(r/min)) | 2.1/7000 | 5.0/7000 | 5.8/7000 |
| Max torque (N·m/(r/min)) | 7.0/7000 | 8.6/7000 | 9.3/7000 |
| Ignition | C.D.I | C.D.I | C.D.I |
